FTTH CABLES

CENTRAL-TUBE AIRBLOWN MICRO CABLE (2-12F)

Application

  • Inside building, suitable for Indoor use.

Typical Cross Section Of 4 F Air Blown Cable

Cable Construction Details

  • Up to 4 enhance low water peak single mode fibers in full compliance with ITU-T-G.652.D (also available with G655 / G656 / G657 SM Fiber)
  • Loose buffer tube fully filled
  • ARP/KRP/FRP rod as a strength member inside the loose tube
  • nsect & Termite resistance PA-12 outer sheath, Orange

Technical Characteristics-Air Blown & Unitube Micro Cable

FIBER COUNT DIAMETER (mm) Nominal WEIGHT (Kg./Km) Nominal TENSILE STRENGTH (N) BENDING RADIUS (mm) TEMPERATURE RANGE (IEC 60794-1-2-F1) CRUSH RESISTANCE (N)
Installation Operating Temporary Permanent Installation Operating (IEC 60794-1-2-E3)
2F 1.7 2.3 40 20 10D 20D -20° to +50° C -40° to +70° C 100 N/(10x10cm)
4F 1.9 2.9 40 20 10D 20D -20° to +50° C -40° to +70° C 100 N/(10x10cm)
UP TO 12F 2.5 6 150 75 10D 20D -20° to +50° C -40° to +70° C 500 N/(10x10cm)
UP TO 12F 3.8 12 200 100 10D 20D -20° to +50° C -40° to +70° C 1000 N/(10x10cm)

Color Coding – Fiber

  • Blue
  • Orange
  • Green
  • Brown
  • Grey
  • White
  • Red
  • Black
  • Yellow
  • Violet
  • Pink
  • Aqua

Special Features

  • Completely dielectric cable / non metallic cable immune to electromagnetic interferences
  • Suitable for Micro duct Installation

Drum Length

  • 2000/3000/4000 meters ± 5%

Mechanical Characteristics

Repeated Bending (IEC 60794-1-2-E6) 30 Cycle, 20 X D, 1 Kg Load, D = Cable Diameter
Torsion Resistance (IEC 60794-1-2-E7) 2 Cycle (± 180°) 1 Kg Weight, L= 2 Mtr
Kink Resistance (IEC 60794-1-2-E10) 15 x D, D = Cable D
